Are you looking for a compact overdrive-booster? Do you need something more than the standard three-knob overdrive? Effect which does not spoil the sound and has a clean and dynamic output with a nice and transparent tone? And you want that effect for a booster and overdrive? With nice extended control over the middles? And you want it to look nice and be different? So you want something really good and functional! You need fire in your hands, get your Firesound V3 now!
N-audio Firesound ver.3, our bestseller, is an ultimate boutique high quality 100% analog booster-overdrive. Hand-soldered and designed uncompromisingly, this pedal guarantees excellent sound and flawless work in combination with unique design which we stand by. This effect is based on the classic 3-potentiometer overdrive controls: Gain, Tone and Level, plus some extra features. Due to the innovative schematics resolutions and the high quality parts used in N-audio Firesound, it provides you with a splendid, transparent and full of action tone. This small and compact pedal is ideal for boosting tube amplifiers, working with any hybrids or solid state amps or in combination with other effects.
What is more, Firesound ver.3 has three more features which give you flexibility to create almost any tone with your overdrive.
3-position small switch for changing 3 different presets (P marker on the right).
This unique feature changes the sound between booster, classic overdrive and fat overdrive
The middle boost position is ideal as a booster for almost all amps, drive channels or for playing funk music. This position has a high-pass filter that gives you a compact and clear tone. By increasing the drive, the effect sounds like a dirty oldschool booster.
The lower boost position has the typical overdrive frequency characteristics with a high-pass filter added to it, in order to provide you with the ideal solo tone.
The upper boost position (fat overdrive) has more drive and fatter tone. Ideal for solo, rhythm or for bass guitar overdrive.
Middle boost switch (M marker on the left)
It is a small switch which turns on and off the middles booster feature. This small pot on the left side of the pedal is used to control the middle frequency boost-cut. Also there are 4 fixed frequencies (600Hz, 700Hz, 800Hz and 1Khz), selectable from a small DIP switch at the bottom.
True or buffered bypass
Firesound ver.3 has a unique feature – 2 types of bypass: true bypass and buffered bypass. At the bottom of the PCB, inside the pedal, there is a small switch changing the proper bypass method. True bypass is a feature for guys who need no sound change when the pedal is off. When the pedal works with the buffered bypass, you can boost the bypass level signal up to 15dB using the small trimmer at the right side of the pedal.
Specifications
High quality double sided gold plated PCB's. All parts are hand soldered.
Dimensions: W65/D115/H55mm
Weight: 380gr.
Power consumption @9V : 3mA
N-audio Firesound works with a battery or with an adapter that provides well stabilized power supply of 9-12 volts .
N-audio Firesound comes with 3-year warranty!
